  • GPON Single mode simplex LC UPC Fast Installable Optical Connector For 0.9,2.0,3.0mm Cable

GPON Single mode simplex LC UPC Fast Installable Optical Connector For 0.9,2.0,3.0mm Cable

0 stars, based on 0reviews
Price:
$1.50$1.27 / piece
Quantity: - + 100000items available
Contact Us



GPON Single mode simplex LC UPC Fast Installable Optical Connector For 0.9,2.0,3.0mm Cable

Product details

Product NameField Assembly Optical Connector
ColorBlue Green Customized
Connector Cable Diameter0.9mm 2.0mm 3.0mm
TypeSingle Mode, Multimode
Connector TypeLC/UPC
Insertion Loss< 0.3dB
Return Loss< -45dB
Weight3g
Temperature-40℃to 75℃
ApplicationFTTH FTTX Network
Product KeywordsLC UPC Fast Installable Optical Connector



Description:



The LC fast connector are factory pre-polished, field-installable connectors that completely eliminate the need for hand polishing in the field. Proven mechanical splice technology ensuring precision fiber alignment, a factory pre-cleaved fiber stub and a proprietary index-matching gel combine to offer an immediate low loss termination to either single-mode or multimode optical fibers.



Features:

  1. No epoxy and polishing required
  2. No expensive tools required
  3. Quick and easy fiber termination
  4. Precision mechanical alignment insures low insertion loss
  5. Superior optical performance
  6. Streamlined component design, convenient operation
  7. Pre-installed, on-site assembly without end face grinding and consideration
  8. Uses proven, molded v-groove technologies
  9. Allow optical continuity to be verified by use of visual fault locator (VFL)



Applications:



  • Fast Ethernet,Data Communication LAN and WAN

  • High speed Enterprise servers

  • Multiplexers,switches and routers

  • Optical Access and ATM Networks Equipment

  • Optical Transport and Telecommunications,FTTH,FTTD,FTTX

  • Switching Equipment







GPON Single mode simplex LC UPC Fast Installable Optical Connector For 0.9,2.0,3.0mm CableGPON Single mode simplex LC UPC Fast Installable Optical Connector For 0.9,2.0,3.0mm CableGPON Single mode simplex LC UPC Fast Installable Optical Connector For 0.9,2.0,3.0mm Cable



Installation instructions:
